YW submersible sewage pumps_ submersible sewage pumps_ submersible sewage pump

Contact Supplier

More Products

Product details

1、 Introduction to YW Submerged Sewage Pump

The mechanical seal of YW sewage submersible pump adopts a new type of hard and corrosion-resistant tungsten carbide material, and the seal is improved to a double end face seal, allowing it to operate in the oil chamber for a long time, which can ensure the safe and continuous operation of the pump for more than 8000 hours. YW pump can be used within the full head range without overloading the motor. YW submersible sewage pump can be equipped with a fully automatic safety protection control cabinet according to user needs, which provides absolute protection for pump leakage, electric leakage, overload, and overheating, improving the safety and reliability of the product. The float switch can automatically control the start and stop of the pump according to the required liquid changes, without the need for special supervision, making it extremely convenient to use. The YW submersible sewage pump is equipped with high-precision anti-interference water leakage detection sensors in the sealed oil chamber, and thermal sensitive elements are embedded in the stator winding to provide absolute protection for the water pump motor.


YW submersible sewage pump can be equipped with a dual rail automatic coupling installation system according to user needs, which brings great convenience to installation and maintenance, and people do not have to enter the sewage pit for this. There are two different installation methods, fixed automatic coupling installation system and mobile free installation system.

2、 Scope of use of YW vertical submersible pump

1. Enterprise wastewater discharge

2. Discharge system of urban sewage treatment plant

3. Subway, basement, civil air defense system drainage station

4. Sewage discharge stations for hospitals, hotels, high-rise buildings, and residential areas

5. Discharge of slurry in municipal engineering and construction sites

6. Water supply system of the water plant

7. Wastewater discharge from breeding farms and irrigation of rural farmland

8. Exploration of mines and supporting water treatment equipment

timg (3)_副本.jpg

3、 Performance parameter table of YW submersible sewage pump

model	Flow rate m3/h	Head m	Speed r/min	Power kw
25YW2-10-0.37	2	10	2900	0.37
25YW4-10-0.55	4	10	2900	0.55
25YW6-10-0.75	6	10	2900	0.75
25YW6-15-1.1	6	15	2900	1.1
25YW10-15-1.5	10	15	2900	1.5
25YW10-20-2.2	10	20	2900	2.2
32YW8-12-0.75	8	12	2900	0.75
32YW6-15-1.1	6	15	2900	1.1
32YW12-15-1.5	12	15	2900	1.5
32YW10-20-2.2	10	20	2900	2.2
40YW10-10-0.75	10	10	2900	0.75
40YW8-15-1.1	8	15	2900	1.1
40YW8-20-1.5	8	20	2900	1.5
40YW12-15-1.5	12	15	2900	1.5
40YW15-20-2.2	15	20	2900	2.2
50YW27-5-0.75	27	5	2900	0.75
50YW20-7-0.75	20	7	2900	0.75
50YW15-8-0.75	15	8	290	0.75
50YW10-10-0.75	10	10	2900	0.75
50YW10-12-1.1	10	12	2900	1.1
50YW33-7-1.1	33	7	2900	1.1
50YW40-7-1.5	40	7	2900	1.5
50YW25-10-1.5	25	10	2900	1.5
50YW20-15-1.5	20	15	2900	1.5
50YW15-15-1.5	15	15	2900	1.5
50YW10-18-1.5	10	18	2900	1.5
50YW15-20-2.2	15	20	2900	2.2
50YW15-18-2.2	15	18	2900	2.2
50YW15-25-2.2	15	25	2900	2.2
50YW27-15-2.2	27	15	2900	2.2
50YW30-14-2.2	30	14	2900	2.2
50YW42-9-2.2	42	9	2900	2.2
50YW30-10-2.2	30	10	2900	2.2
50YW20-22-3	20	22	2900	3
50YW25-18-3	25	18	2900	3
50YW15-30-3	15	30	2900	3
50YW25-20-4	25	20	2900	4
50YW30-18-4	30	18	2900	4
50YW40-15-4	40	15	2900	4
50YW20-30-5.5	20	30	2900	5.5
50YW25-25-5.5	25	25	2900	5.5
50YW20-40-7.5	20	40	2900	7.5
50YW25-35-7.5	25	35	2900	7.5
50YW30-30-7.5	30	30	2900	7.5
50YW30-40-7.5	30	40	2900	7.5
65YW25-10-1.5	25	10	2900	1.5
65YW35-7-2.2	35	7	2900	2.2
65YW30-10-2.2	30	10	2900	2.2
65YW25-15-2.2	25	15	2900	2.2
65YW40-9-3	40	9	2900	3
65YW35-10-3	35	10	2900	3
65YW37-13-3	37	13	2900	3
65YW30-22-4	30	22	2900	4
65YW40-15-4	40	15	2900	4
65YW25-30-5.5	25	30	2900	5.5
65YW40-20-5.5	40	20	2900	5.5
65YW32-25-5.5	32	25	2900	5.5
65YW30-30-5.5	30	30	2900	5.5
65YW40-30-7.5	40	30	2900	7.5
65YW30-40-7.5	30	40	2900	7.5
65YW30-45-11	30	45	2900	11
65YW35-50-15	35	50	2900	15
65YW35-60-18.5	35	60	2900	18.5
80YW40-7-2.2	40	7	1450	2.2
80YW35-9-2.2	35	9	1450	2.2
80YW30-12-2.2	30	12	1450	2.2
80YW50-7-3	50	7	2900	3
80YW45-10-3	45	10	2900	3
80YW43-13-3	13	13	2900	3
80YW40-15-4	40	15	2900	4
80YW65-10-5.5	65	10	2900	5.5
80YW50-20-5.5	50	20	2900	5.5
80YW40-25-5.5	40	25	2900	5.5
80YW30-30-5.5	30	30	2900	5.5
80YW65-25-7.5	65	25	2900	7.5
80YW80-15-7.5	80	15	2900	7.5
80YW40-30-7.5	40	30	2900	7.5
80YW30-40-7.5	30	40	2900	7.5
80YW50-35-11	50	35	2900	11
100YW70-6-3	70	6	1450	3
100YW85-10-4	85	10	1450	4
100YW70-15-4	70	15	1450	4
100YW100-10-5.5	100	10	0.5	5.5
100YW65-15-5.5	65	15	0.5	5.5
100YW120-7-7.5	120	7	0.5	7.5
100YW100-10-7.5	100	10	0.5	7.5
100YW85-15-7.5	85	15	0.5	7.5
100YW80-20-7.5	80	20	0.5	7.5
100YW100-15-7.5	100	15	0.5	7.5
100YW100-20-11	100	20	0.5	11
100YW100-25-11	100	25	0.5	11
100YW120-25-15	120	25	0.5	15
100YW100-30-15	100	30	0.5	15
100YW120-30-18.5	120	30	0.5	18.5
100YW100-35-18.5	100	35	0.5	18.5
100YW100-40-22	100	40	0.5	22
150YW150-7-7.5	150	7	1450	7.5
150YW145-9-7.5	1450	9	1450	7.5
150YW110-15-7.5	110	15	1450	7.5
150YW200-7-11	200	7	980	11
150YW150-12-11	150	12	1450	11
150YW200-10-15	200	10	1450	15
150YW180-15-15	180	15	1450	15
150YW180-20-18.5	180	20	1450	18.5
150YW150-26-18.5	150	26	1450	18.5
150YW180-25-22	180	25	1450	22
150YW200-20-22	200	20	1450	22
150YW240-20-30	240	20	1450	30
150YW200-25-30	200	25	1450	30
150YW150-35-37	150	35	1450	37
150YW180-30-37	180	30	1450	37
150YW180-40-45	180	40	1450	45
150YW200-38-45	200	38	1450	45
200YW300-7-11	300	7	980	11
200YW250-11-15	250	11	1450	15
200YW300-8-15	300	8	1450	15
200YW250-15-18.5	250	15	1450	18.5
200YW300-9-18.5	300	9	1450	18.5
200YW400-10-22	400	10	1450	22
200YW360-12-22	360	12	1450	22
200YW300-15-22	300	15	1450	22
200YW450-10-30	450	10	1450	30
200YW400-13-30	400	13	1450	30
200YW300-18-30	300	18	1450	30
200YW250-22-33	250	22	1450	30
200YW450-15-37	450	15	1450	37
200YW300-25-37	300	25	1450	37
200YW400-20-45	400	20	1450	45
200YW350-25-45	350	25	1450	45
200YW250-35-45	250	35	1450	45
200YW450-22-55	450	22	1450	55
200YW400-25-55	400	25	1450	55
200YW300-40-55	300	40	1450	55
250YW600-9-30	600	9	980	30
250YW600-12-37	600	12	980	37
250YW600-15-45	600	15	1450	45
250YW600-20-55	600	20	1450	55
250YW600-25-75	600	25	1450	75
250YW600-30-75	600	30	1450	75
300YW800-7-30	800	7	980	30
300YW800-9-37	800	9	980	37
300YW800-12-45	800	12	1450	45
300YW680-15-45	680	15	1450	45
300YW800-15-55	800	15	1450	55
300YW600-20-55	600	20	1450	55
300YW800-20-75	800	20	1450	75
300YW800-25-90	800	25	1450	90
300YW950-20-90	950	20	1450	90
300YW1000-25-110	1000	25	1450	110
350YW1100-10-55	1100	10	980	55
350YW1180-13-75	1180	13	980	75
350YW1200-15-90	1200	15	980	90
350YW1200-20-110	1200	20	980	110
400YW1800-7-55	1800	7	740	55
400YW1800-10-75	1800	10	740	75
400YW1800-12-90	1800	12	740	90
400YW2000-10-90	2000	10	740	90
400YW2000-13-110	2000	13	740	110
400YW200-15-132	2000	15	740	132
450YW2300-10-90	2300	10	740	90
450YW2250-11-110	2250	11	740	110
450YW2260-14-132	2260	14	740	132
500YW2500-10-110	2500	10	740	110
500YW2500-16-160	2500	16	740	160
600YW5400-8-185	5400	8	740	185
600YW4000-12-200	4000	12	740	200
