Introduction to Golden Sunflower Drying Machine

Golden Sunflower, also known as Vegetable Hibiscus or Wild Hibiscus, is an annual herbaceous plant belonging to the Malvaceae family and the Okra genus. Its fresh fruits, leaves, and stems are rich in various amino acids and trace elements.

The Golden Sunflower Drying Machine consists of four parts: feeding conveyor, drying system, heat source, and discharging conveyor. The feeding conveyor has a material equalization device, which evenly spreads the material and can adjust the gear thickness according to the drying requirements of the sunflower. Achieve the goal of uniform feeding. The feeding machine does not require additional transmission devices and is driven by the motor of the drying system. The contact surface of the dryer body is made of 304 stainless steel, which is a food grade material and will not contaminate the sunflower. Each layer is equipped with a blocking device to ensure that the golden sunflower is evenly conveyed and dried in an S-shape.




The internal frame support of the dryer is made of hot-dip galvanized steel pipes, which are corrosion-resistant and will not damage or contaminate the sunflower. The main purpose of the top opening of the box is to remove moisture. Golden sunflower itself has a certain thickness, and the heat generated inside generates internal heat, evaporation heat, to avoid high humidity and inability to dry. The air volume is high and the wind pressure penetrates, so there is no need to seal it, and the generated steam can be discharged.

There are various heat sources for dryers, such as coal, air source heat pumps, natural gas, diesel, steam, biomass pellets, etc., which can be configured according to the actual situation of the customer's local area.

The peach blossoms dried using the Baixin belt type golden sunflower dryer have good color, low damage rate, and high returns. The network speed, temperature, and humidity can be adjusted according to production needs to meet the drying treatment of different moisture contents and varieties.

Principle of Golden Sunflower Drying Machine

The golden sunflower enters from the upper layer, and the thickness of the peach blossom material is controlled by an automatic feeder. Under the drive of the mesh belt, the peach blossoms move from the upper layer to the lower layer. During operation, peach blossoms undergo multiple downward movements, resulting in more thorough and even drying of the peach blossoms. The dried peach blossoms are discharged from the bottom outlet, and during this process, they are fully exposed to high-temperature hot air to achieve a drying effect.

Characteristics of Golden Sunflower Drying Machine

1：The mesh belt type golden sunflower dryer is known as the through flow mesh belt dryer. Hot air enters the dryer from the bottom through the induced draft fan for bottom-up penetrating drying. The air volume is large enough to fully dry the golden sunflower.

2: High degree of automation, capable of continuous operation.

3: Fully automatic electronic control, easy to operate, saving power and effort.

4: Large production capacity, different models can meet the needs of different scales.

Characteristics of Golden Sunflower Drying Machine Equipment

1：The equipment adopts a speed regulating motor, which can adjust the running time of golden sunflower in the dryer according to different moisture contents, thereby improving efficiency while ensuring the drying effect.

2: The heat source of the dryer uses a coal-fired heat exchange furnace, and the outlet temperature can reach 170 ℃. In order to maintain the good shape, color, and internal structure of materials such as food, medicinal herbs, fruits, vegetables, etc., and improve production quality, the drying inlet temperature of the golden sunflower dryer is controlled between 60 ℃ -90 ℃; The heat source adopts heat exchange method, and the heat carrier entering the dryer is clean, so that the golden sunflower will not be contaminated.

3: There are 8 slag removal doors installed at the bottom of the equipment, which can quickly and conveniently clean the equipment.

4: The device has a wide range of applications, simple operation, and easy maintenance.

Application fields of Golden Sunflower Drying Machine

The golden sunflower dryer dehydrates and dries quickly and is easy to operate. To meet the demand for large-scale continuous production, the dryer is applied to the dehydration and drying of sheet, strip, block, and granular materials in food, dried fruits (dates, almonds, cashews, pistachios), flower tea (roses, chrysanthemums, honeysuckle, lilies), agricultural and sideline products (such as corn and peanuts), dehydrated vegetables (such as garlic, ginger slices, chili, horseradish, onions, radishes, ginger, scallions, horseradish, spinach), fruits (such as papaya, potato chips, hawthorn slices, raisins, cantaloupe), Chinese herbal medicine, aquatic products (forsythia, okra, goji berries), local specialty products, feed, and chemical raw materials.

Installation and after-sales service

1. Installation service

Our company sends personnel to the customer's site to guide the installation of equipment and provide technical training. The construction site requires the cooperation of three people from the demand side for installation.

2. Training

After the equipment installation is completed, our company is responsible for training the entire production line operators, so that they can proficiently operate, maintain, master general fault analysis, and be able to independently troubleshoot faults.

3. After sales service

The product has a one-year warranty period; During the warranty period, any malfunctions caused by the product's own quality will be repaired free of charge; Implement limited time service for equipment maintenance, with general faults handled within 24 hours for projects within the province and on-site within 48 hours for projects outside the province.
