1. The 4.5-meter folding cutting platform ensures smooth, efficient, non clogging, and reliable crop production. Adopting full hydraulic drive, it can achieve one key switching between forward and reverse rotation, and automatically clear blockages.
2. Equipped with internationally leading high-end intelligent metal detectors, the feeding roller detects metal foreign objects and immediately stops to protect the entire machine.
3. The feed cutting length is infinitely adjustable from 8-18mm, and it can be quickly reversed by hydraulic pressure.
4. Drum electric control automatic sharpening, no need for manual sharpening, safe and fast, reduces power consumption and fuel consumption, improves cutting effect and harvesting efficiency.
5. The control system is modular, integrated, intelligent, equipped with high-performance LCD display screen, parameter monitoring, and easy to adjust intuitively
6. Equipped with an automatic lubrication system, almost all bearings are lubricated in real time, improving machine reliability and harvesting efficiency.
7. The fully static hydraulic drive continuously variable transmission system ensures flexible walking of the entire machine.
8. Equipped with a 458 horsepower Shangchai National III electronic fuel injection diesel engine, it has strong power, reliability, durability, high efficiency, fuel efficiency, and low maintenance costs.
Machine model |
9458 |
Overall dimensions(m)(Transportation status) |
7.62×3×3.9 |
total machine weight(kg) |
13500 |
engine power(kw) |
337 |
Engine output speed(r/min) |
1900 |
Width of high stem cutting platform(m) |
4.4 |
Cutting height(cm) |
≤15 |
feed rate(T/h) |
≤90 |
Structure type of shredding blade |
Combined curved blade(24Film) |
Cut length(mm) |
8-18 (Four adjustable gears) |
Scope of throwing materials(°) |
±110 |
Throwing height(m) |
4.9~5.9 |
行走速度(km/h) |
0-20 |
Grain crushing device |
standard configuration |
